ROMY: Rotational Motions in Seismology
by Jonas Igel
ROMY is a rotational motion sensor at the LMU Munich. Its technology is based on the Sagnac effect where two lasers are sent in opposite directions and the phase shift is measured which correlates to ground rotation. With its four rings, ROMY is the most sophisticated ring laser in the world at the moment. Visible here is the point where three of those rings meet.
Taken on 7
June
2017
Submitted on 13 February 2020
Categories
Location
- Europe (3253)
- Western Europe (653)
- Germany (225)
- Exact location (11.2755 E, 48.1629 N)
Tags
laser, sagnac, ring laser, lmu
Colour distribution
Download original file
3456 × 5184 px;
image/jpeg; 2.3 MB
Camera:
Canon EOS 600D
Software: Lightroom
Licence
Credit: Jonas Igel (distributed via imaggeo.egu.eu)
